Automatic Pouch Flat Surface Label Applicator Labeling Machine For Detergent Perfume Bottle

  • Product Item：YTK-300
    • Automatic flat square bottle labeling machine  , Automatic pouch flat surface label applicator  , Flat bottles Surface Self Adhesive Sticker
    Inquiry Send Email

    Description


    ♦Introduction♦

    Automatic Pouch Flat Surface Label Applicator Labeling Machine For Detergent Perfume Bottle

    YTK-300 plane labeling machine for the whole high grade stainless steel and high grade aluminum alloy, labeling head using high speed servo motor to ensure the accuracy and speed of labeling, all the electronic and control systems are also used in Germany, Japan and Taiwan imported high end products, PLC with man machine interface control ,simple operation clear.

    ♦Technical Parameters♦

    Model
    YTK-300
    Machine size
    L2000×W550×H1600mm
    Output speed
    60-350PCS/min(depends on actual object)
    Object Height
    30-210mm
    Object Thickess
    20-120mm
    Label Height
    15-200
    Label length
    25-300
    Precision
    ±1mm
    RolI Inside Diameter
    76mm
    Roll outside Diameter
    300mm
    Power supply
    220V 50/60HZ 1.5KW
    Weight
    300kg

    ♦Product Detailes♦

    Automatic Pouch Flat Surface Label Applicator Labeling Machine For Detergent Perfume Bottle

    Automatic Pouch Flat Surface Label Applicator Labeling Machine For Detergent Perfume Bottle

    Automatic Pouch Flat Surface Label Applicator Labeling Machine For Detergent Perfume Bottle

    ♦Application♦

    Automatic Pouch Flat Surface Label Applicator Labeling Machine For Detergent Perfume Bottle




    Automatic Pouch Flat Surface Label Applicator Labeling Machine For Detergent Perfume BottleAutomatic Pouch Flat Surface Label Applicator Labeling Machine For Detergent Perfume Bottle
